Wheel Hub Bearing 7466964

Front Axle
Flange Diameter: 5.69 In.
Bolt Circle Diameter: 4.75 In.
Wheel Pilot Diameter: 2.76 In.
Brake Pilot Diameter: 2.78 In.
Flange Offset: 2.93 In.
Hub Pilot Diameter: 3.21 In.
Hub Bolt Circle Diameter: 4.75 In.
Bolt Size: M12X1.5
Bolt Quantity: 5
Bolt Hole MET: M12X1.75
Bolt Hole qty: 3
Flange Shape: MODIFIED TRIANGLE
ABS Sensor: Has ABS with Tone Ring Sensor
Number of Splines: 27


Make

  • CHEVROLET
  • GM
  • OLDSMOBILE

ManufacturersHow to join supplier

Model

Chevrolet S10 1991-1996 4WD, 4-Wheel ABS
Chevrolet S10 1997 4WD, 4-Wheel ABS, 1st Design
Chevrolet S10 Blazer 1995-1997 4WD
Chevrolet S10 Blazer 1991-1994 4WD, 4-Wheel ABS
Chevrolet S10 Blazer 1997 4WD, 4-Wheel ABS, 1st Design
GMC Jimmy 1994-1996 4WD
GMC Jimmy 1991-1994 4WD, 4-Wheel ABS
GMC Jimmy 1997 4WD, 4-Wheel ABS, 1st Design
GMC Sonoma 1991-1996 4WD, 4-Wheel ABS
GMC Sonoma 1997 4WD, 4-Wheel ABS, 1st Design
Oldsmobile Bravada 1991-1994
Oldsmobile Bravada 1996-

REF NO.

Factory Number Number
BCA 5130** 5130**
FAG FW96* FW96*
OE 74669** 74669**
OE 74700** 74700**
Factory Number Number
OE 74700** 74700**
OE 74705** 74705**
SKF BR9300** BR9300**
TIMKEN 5130** 5130**
